Specifications
RATINGS · VOLTAGE OPTIONS · CORE MATERIAL
| Capacity | 25 – 333 kVA |
|---|---|
| System Voltage | Up to 35 kV |
| Frequency | 50 or 60 Hz |
| Insulation Class | A class |
| Core Material | HGO or amorphous ribbon |
| Insulating Oil | Mineral, high fire-point mineral or ester base oil |
| Standard | IEC, IEEE or specified by customers |
LV plate type terminals.
Over current interrupter.
Stainless steel tank.
Temperature versus load curves.
● Product Features
-Fully insulated HV and LV terminals
-High grade of HGO or amorphous core is adopted reducing the core loss dramatically
-Customized and optimized designs meet or exceed the requirements of international standards
● Standard Accessories
-HV bushing wells & LV comb type terminals
-Bayonet fuse and back-up current limiting fuse
-HV tap changer
-Oil level gauge & thermometer
-Pressure relief device & drain valve
-Nameplate & grounding pad
-Fully insulated HV and LV terminals
-High grade of HGO or amorphous core is adopted reducing the core loss dramatically
-Customized and optimized designs meet or exceed the requirements of international standards
● Standard Accessories
-HV bushing wells & LV comb type terminals
-Bayonet fuse and back-up current limiting fuse
-HV tap changer
-Oil level gauge & thermometer
-Pressure relief device & drain valve
-Nameplate & grounding pad
Need customized voltage configurations or utility-standard transformer designs?
